How can I integrate CAD with manufacturing?

SWOOD CAM

SWOOD CAM manages NC machines dedicated to woodworking and their technologies. Generate your programs and production documents directly inside SOLIDWORKS, using specialised tools.

Easily create or drag and drop toolpaths onto components to speed up the time it takes to start machining.
Simplify complex operations with dedicated tools for drilling blocks, aggregates, edgebanding and horizontal spindles.
Simulate toolpaths to check your machining intent and produce code for a variety of woodwork machines.

Get Pricing

Book a Demo

SWOOD CAM Data Sheet

SWOOD CAM Library

Generate and customise your library by adding various tools and aggregates. Multiple and horizontal spindles can easily be generated in the aggregates wizard. Utilise machining macros to quickly apply operations via drag and drop.

SWOOD CAM Technology

SWOOD CAM has a variety technologies to help you with your woodwork machining. These include automatic feature recognition for contouring, drilling, pocketing and grooving. As well as 3D and multiaxis milling for complex geometries.

In addition to this modualtion of feedrate according to grain direction, suction hood management and compatibility for flatbeds and pod and rail beds give great industry specific customisations

SWOOD CAM Encoding

Getting your design to the machine has never been easier with SWOOD CAM. With its specialised post processing it accommodates the needs for woodworking and offers excellent compatibility with Biessie, Homag and SCM.

SWOOD CAM Capabilities

Technology

3, 4 & 5 axis machining
Automatic feature recognition – Contour, Drill, Pocket, Groove & more
Automatic modulation of feed speed according to grain direction
Multiple datum definition
Flat bed or pod and rail machine compatible
Laser layout projection
Suction hood management
Parametric worktable management

SWOOD CAM Library

Generate and customise your library by adding various tools and aggregates.
Multiple and horizontal spindles can easily be generated in the aggregates wizard.
Utilise machining macros to quickly apply operations via drag and drop.

Fully Integrated into SOLIDWORKS

Manufacturing Tools in the Feature Manager
Machining simulation in SOLIDWORKS view including machine environment
Material removal simulation
Parametric tool paths associated with SOLIDWORKS

Encoding

Part and assembly programming
Multiple machine language outputs
Compatible with a range of machine manufacturers: » BIESSE » HOMAG » SCM

Reporting

Customisable Formatting
Programming List
Tool List
Program Labels
